PMA-600NE
2 Ch. 45W Integrated Amplifier

Featuring Bluetooth streaming, digital inputs and a built-in phono equalizer, the Denon PMA-600NE integrated amplifier sets new heights in audio performance and connectivity for the aspiring music enthusiast.

• Stereo amplifier
• 45W per channel (8 ohms)
• Advanced circuitry
• Bluetooth
• Digital inputs
• MM phono

Your introduction to what a premium amplifier can do

Listen to your favorite high-resolution audio content with the 192kHz/24bit D/A converter or connect and stream via Bluetooth.

Micro-processor stop mode

The integrated micro-processor stop mode protects the audio signal from external noise.

MM phono

High performance MM phono equalizer to connect your turntable and enjoy vinyl tracks.

Bluetooth and connectivity

Extend your audio experience with nearly unlimited sources.

Add power to your Hi-Fi experience

Engineered with remarkable Denon amplifier technology, the PMA-600NE delivers 70 Watts of power-per-channel at 4 Ohm. This integrated amplifier offers compatibility with the widest range of speaker types and impedances for operational stability.

Channels

2

Digital in: USB-B / optical / coaxial / USB-A

No / 2 / 1 / No

Sample Rate digital In

192 kHz / 24-bit

DAC chip

PCM5141

Bluetooth / aptX / NFC

Yes / No / No

Analogue Mode

Yes

Advanced HC-TR single push pull circuit

Yes

Wide range amplifier

Yes

High current dynamic power supply

Yes

Power amp discrete construction

Yes

Micro processor auto off

Yes

Balance / Bass / Treble / Loudness

Yes / Yes / Yes / No

Shottky diodes

Yes

Solid Heat Sinks

Yes

Source Direct

Yes

Audio Inputs

5

Digital in: USB-B / optical / coaxial / USB-A

No / 2 / 1 / No

Phono Input: MM / MC

Yes / No

Audio Outputs

1

Pre-out / Main-in

subwoofer / No

Gold plated Cinch

Yes

Number of terminals

2

Remote Control Bus in / out

Yes

HEOS Link compatibility: IR / IP

Yes / No

Headphone Out

Yes

Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%)

45 W

Output power 4 Ohm (1 kHz, T.H.D. 0.7%)

70 W

Total Harmonic Distortion

0.02%

Input Sensitivity: MM

2.5 mV / 47 kohm

Signal to Noise Ratio: MM/MC

84 dB / No

Input Sensitivity: High level

110 mV / 30 kohms

Signal to Noise Ratio: High level

105dB

Treble Control

± 8 dB at 10 kHz

Bass Control

± 8 dB at 100 Hz

Music Hall MMF-1.5 Turntable

Description

Product Highlights:

• Gorgeous real cherry wood veneer
• Built-in bypassable phono pre-amplifier
• 9" S-shaped aluminum tonearm with removable headshell for easy cartridge changing
• Low noise three-speed belt-drive motor provides 33⅓, 45, and 78 rpm
• Properly aligned and mounted Music Hall Melody ($75 value) moving magnet cartridge
• Adjustable electronic speed control
• Special vibration-damping feet

Dimensions and Warranty:

• Dimensions: 17.1" x 14.5" x 5"
• Weight: 12 lbs.
• Warranty: 1 year

All About Music Hall MMF-1.5 Turntable

The Music Hall MMF-1.5 turntable is a beautifully refined piece that sets your world to groove and your feet to dance. Its superior S-shaped alloy tonearm, top-quality Music Hall Melody cartridge, and 3-speed belt drive design deliver exceptional sound quality, while the built-in phono preamp allows you to connect directly to your current system. The included hinged dust cover keeps your MMF-1.5 protected when not in use. With a built-in speed control circuit, the MMF-1.5 ensures the accuracy of its 3 speeds, providing you with an immersive listening experience from start to finish.

Music Hall MMF-1.5 Turntable Specs

Turntable
Type: 3-speed full manual
Motor: DC motor
Driving Method: Belt drive
Platter: 305mm dia. aluminum die-cast
Speeds: 33 1/3, 45, and 78rpm
Wow & Flutter: less than 0.1% WTD at 3KHz RMS(CD-4005)
Limit: Less than 0.15% WTD at 3KHz RMS(CD-4005)
S/N Ratio: More than 65dB (DIN-B) (SS-4242)
Limit: More than 62dB (DIN-B) (SS-4242
Speed Tolerance: 3000Hz +/-1%(CD-4005)
Power Supply: DC12V，2.0A
Universal Power Supply
Consumption: 4W
Dimensions (WxDxH): 17.1" x 14.5" x 5" (435x367x127mm)
Weight: 12lbs. (5.4Kg)

Cartridge
Included Cartridge: Music Hall Melody
Output Voltage: 2.5mV +/- 3dB at 1KHz 3.54cm/sec
Channel Separation: measurement point 1KHz over 18dB
Channel Balance: 25 dB or less at 1KHz
Frequency Response: measurement point 10KHz / 1KHz 0 +/- 3dB
Tracking Force: 2.0 +/- 0.5 grams
Cartridge Type: Moving Magnet
Stylus: Diamond
Channel Separation: More than 15 dB at 1KHz (CD-4005)
Channel Balance: Within 2.5 dB at 1KHz (CD-4005)
Phono Output Level: 1.5~3.6 mV at 1KHz 5cm/sec (CD-4005)
Line Output: 90-216 mV at 1KHz 5cm/sec (CD-4005)
RIAA: 20Hz~20KHz: +1/-3 dB

Tonearm
Type: static balanced S-shaped
Effective Arm Length: 230mm
Overhang: 15mm
Offset Angle: 22 degrees
Tracking Error Angle: 3 degrees or less
Rotation Movability: (1-rotation 4g)
Applicable Cartridge Weight: 5~8.5g (including headshell 15~18.5g)
Anti-Skating Adjustment Range: 0~3g
Arm Lifter: Oil damper type
Height Of Stylus: 8~10.5mm
Lifter Descent Time: 1.5~3 sec (stylus pressure: 2g)
Horizontal Sensitivity: less than 0.2g
Vertical Sensitivity: less than 0.2g

Klipsch
RP-600M II

BOOKSHELF SPEAKERS

BIGGER HORN, BETTER SOUND

A new, larger 90^° x 90^° silicone composite hybrid Tractrix^® horn provides incredibly efficient transfer of high-frequency waves into the listening area for crisper, clearer sound. The phase plug and compression molded silicone face ensure smooth frequency response.

LINEAR TRAVEL SUSPENSION (LTS) TITANIUM DIAPHRAGM TWEETER

The exclusive 1" LTS minimizes distortion for enhanced, detailed performance. LTS tweeters are a hallmark of previous Reference Premiere Series, making it a core component of some of the best speakers in the world.

VENTED TWEETER DESIGN

The vented tweeter housing reduces standing waves that create unwanted harmonics, resulting in enhanced detail and clarity in high-frequency reproduction.

ALL-NEW CERAMETALLIC WOOFER

A signature feature on the Reference Premiere series speakers, the 6.5" Cerametallic^™ woofer has been updated for absolutely flawless sound reproduction, minimum distortion, and maximum efficiency. The redesigned woofer will deliver the power, detail, and emotion you expect from a Klipsch Reference Premiere speaker.

TRACTRIX PORT

Utilizing Tractrix geometry, the Reference Premiere port allows for the most efficient, fastest air transfer from the cabinet, which reduces port noise for punchier low frequencies and cleaner, more powerful bass.

BI-WIRING
BI-AMPING CAPABILITY

Dual input terminals for bi-wiring / bi-amping capabilities separate high and low-frequency current into different speaker cables, reducing distortion for clearer midrange. Bi-amping allows for further optimization of performance with separate outboard power amplifiers for the high frequency and low-frequency drivers.

The SANUS Basic Foundation Series BF24B Wood Speaker Stands feature:

• A beautiful, black-ash finish.
• 20 lb top-plate weight capacity.
• Twin contoured pillars aligned in a "V" configuration to offer secure support and style
• A hidden cable management system with a snap-in, curved black cover to hold wires in place and hide them from both front and back view.
• A softly curved black base.
• MDF (Medium Density Fibercore) construction, offering more strength than plywood or particle board and ensuring immunity from resonance.
• Force-fit floor spikes to further minimize resonance and provide stability in carpeting.
• Special, triangular top plate isolation pads for speaker protection and acoustic isolation.
• Price is per pair.
• Top Plate Dimensions: 6.5" x 6.5"
• Base Plate Dimensions: 12.5" W x 11" D
