A-S801 Integrated Amplifier

Enjoy USB DAC functionality coupled with high fidelity. ToP-ART circuitry, Pure Direct, refined construction and stunningly good looks offer superior musicality with rich, natural sound.

• 100 W x 2-ch (20 Hz - 20 kHz)
• USB DAC function supports native DSD resolutions (2.8 MHz / 5.6 MHz) and PCM (384 kHz / 32-bit)
• Digital signal indicator shows DSD and PCM playback formats and sampling frequencies
• High efficiency ESS Technology 32-bit DAC (ES9010K2M)
• Digital audio inputs for TV or Blu-ray Disc™ player
• CD Direct Amplification and Pure Direct
• High strength chassis with double-bottom design for excellent dampening of vibrations
• ToP-ART (Total Purity Audio Reproduction Technology) and high quality parts
• I/O (input to output) direct symmetrical design
• ART (Anti-Resonance and Tough) Base
• Custom made power transformer / 12,000 µF block capacitors / extruded aluminum heat sinks
• Gold plated speaker terminals and RCA terminals
• Continuously Variable Loudness Control

High Sound Quality Circuit Design Based on the ToP-ART (Total Purity Audio Reproduction Technology) Concept

ToP-ART Design and ART Base ensure optimum sound when processing and transmitting the audio signal. The signal is simple and direct, therefor it is less likely to be affected by noise and distortion. The left and right channels are organized in a straight, symmetrical layout for the highest signal purity.

High Strength Chassis Contributes to High Density Sound and Pure Audio Reproduction

In order to effectively dampen the vibrations that have adverse effects on sound quality, the A-S801 chassis has a double bottom design with a 1 mm iron plate. In addition, the power transformer and heat sinks in the power amp section are supported by an extremely strong and stable ART (Anti-Resonance and Tough) base. A solid center bar further enhances high rigidity and dampens vibrations. These Yamaha design innovations contribute to superior signal to noise ratio with rich, natural sound reproduction.

High Quality Parts for Outstanding Audio Performance

Notice a custom made power transformer, custom made block capacitors, two direct signal path speaker relays, one point grounding system, extruded aluminum heat sinks and other top quality parts to effortlessly handle demanding audio conditions. The quality of each individual part, as well as how they work together, basically determines the sound quality of this component. Yamaha uses only very high quality parts, carefully selected and tested for their sound properties.

USB DAC Function Supports Native DSD (2.8 MHz / 5.6 MHz) and PCM (384 kHz / 32-bit) Resolutions

The USB DAC function supports native DSD (2.8 MHz and 5.6 MHz) and PCM (384 kHz / 32-bit*) resolutions. This function allows for a direct connection to PCs which opens the door to play back of the highest resolution audio content offered today. The Yamaha-developed USB device controller has its own master clock that eliminates PC jitter. The driver is a low loss, high throughput ASIO 2.3 Yamaha Steinberg USB driver. During playback, indicators on the front panel clearly show which sampling frequencies are currently being used.

*Windows supported. Mac® support is 24-bit.

Exceptionally High Performance 32-bit D/A Converter

After careful listening evaluations, Yamaha selected the 32-bit, 2-channel SABRE™ Premier Audio DAC from ESS Technology, Inc. Most notable is its high precision processing power of 32-bit audio along with the ability to handle large amounts of audio data with full PCM 384 kHz and native DSD 5.6 MHz. Since the built-in D/A converter generates its own master clock, an original jitter elimination function is also included, permitting D/A conversion with an extremely low impact of clock jitter. Moreover, a 2-channel D/A converter is housed inside the chip which applies a double differential operation. The result is exceptional high performance and high quality signal output with a superior signal to noise ratio.

Digital Audio Input for TV and/or Blu-ray Disc™ Player

The A-S801 is equipped for digital audio inputs with an optical and digital coaxial input terminal. The optical is for receiving audio from a TV and the coaxial for receiving audio from a Blu-ray Disc player. The audio stays in the digital domain giving you pure, pristine and dynamic sound for all your entertainment sources.

CD Direct Amplification and Pure Direct Mode for Greater Sound Purity

With a straight connection to the CD input, CD Direct Amplification maximizes the CD sources signal-to-noise ratio. Additionally, engaging the Pure Direct mode causes the music signals to travel the shortest possible circuit route, bypassing the buffer amp, the tone, loudness and balance controls to virtually eliminate any signal degradation for the purest sound quality.

Continuous Variable Loudness Control

The A-S801 also features a new analog loudness control on the front panel that uses electronic volume for higher sound quality which lets you adjust the loudness effect as desired. Separate from the overall volume, this controls the balance of the low and high frequencies providing full tonal range at any volume level by compensating for the natural loss in the human ear at soft levels.

Gold Plated Terminals

Gold plated terminals ensure a high quality connection that prevents signal loss. The A-S801 has gold plated speaker and input terminals.

Speaker A, B or A+B Selection and Speaker Terminals for Two Systems

You can connect two separate speaker systems and hear them in different rooms at the same time. There are four terminals, so by just rotating a simple selector dial you can switch between the two pairs of speakers to play the selected source.

Subwoofer Terminal

A terminal for connecting a subwoofer is provided, allowing you to increase the bass output of your system for a more powerful sound with better overall sound quality.

Phono MM Terminal

You can connect a turntable with a MM phono cartridge to play vinyl records. Get the best of both worlds whether listening to analog vinyl or the latest digital technology.

Simple Yet Sophisticated Design

With a beautiful, simple and unique design inherited directly from Yamaha Hi-Fi audio components, this amplifier also boasts an easy to operate layout. The aluminum front panel has a richly textured silver hairline finish. The main control knobs are also of the same aluminum finish as used on our top end models.

Remote Control with Clean, Simple Design

The clean, simple design of the remote control provides easy to understand “one handed” operation. The design makes it simple to adjust inputs, volumes and more. The unit has a sophisticated looking hairline finish that matches the design of the amplifiers. You can also use the remote to control a Yamaha CD player.

Rotary Encoder Input Selector with LEDs

The rotary encoder makes it quick and easy to select input sources. The luxurious hairline finish offers a nice tactile feeling. LEDs clearly show which source is selected so you can easily switch sources, even in a dark room.

Connection for YBA-11 Bluetooth® Wireless Adapter

With the YBA-11, you’ll be able to stream music wirelessly from a Bluetooth® compatible mobile phone or a PC. Thanks to the digital coaxial connection and the aptX® audio coding algorithm, you’ll enjoy wireless music streaming with optimum sound quality. You can also conveniently power the YBA-11 via the DC out connection on the rear panel of this amplifier.

Auto Power Standby Function

When Auto Power Standby is engaged the amplifier will automatically shift itself into standby mode when a user function has not been executed in eight hours. This a great function if you forget to turn the amplifier off and it will help minimize power consumption when the unit is not in use.

Receiver / Integrated Amplifier

Minimum RMS Output Power (8 ohms, 20 Hz-20 kHz)

High Dynamic Power/Channel (8/6/4/2 ohms)

Damping Factor

Frequency Response

Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz)

Signal-to-Noise Ratio (CD)

Audio In / Out

Digital Input

USB Input

Subwoofer Out

DC out

Pure Direct

ToP-ART

Switchable CD Direct Amplification

Standby Power Consumption

Power Management (Auto Power Standby)

Dimensions (W x H x D)

Weight

Cambridge Audio
Compact Network Player MXN10

The MXN10 network player brings high-resolution streaming to your hi-fi setup or desktop system. With its compact, half-width size, it fits seamlessly into any space while delivering access to an endless library of digital music. Whether streaming or playing from USB or NAS drives, MXN10 brings it all together in one sleek, easy-to-use unit—fully controlled through our StreamMagic app.

The revolution will be streamed

MXN10 brings limitless high-resolution streaming to any system. Enjoy Spotify Connect, TIDAL Connect with MQA, Amazon Music, Qobuz, Deezer, Internet Radio, Apple AirPlay 2, Chromecast Built-in, and more, all with seamless, high-quality playback.

Our streaming expertise, perfected

Developed over a decade of innovation, our in-house streaming platform, StreamMagic Gen 4, delivers fast, stable playback, ensuring seamless performance, rock-solid reliability, and future-proof updates.

Small in size, big on connectivity

With USB playback, Bluetooth 5.0, RCA, coaxial, and optical outputs, MXN10 fits effortlessly into any system while offering high-resolution playback up to 768kHz 32-bit PCM and DSD512.

MXN10 is the ultimate gateway to high-resolution streaming, seamlessly integrating into any system. Designed for those who want premium sound without the complexity, it delivers effortless access to every major streaming service, flexible connectivity, and an intuitive listening experience

ESS SABRE ES9033Q DAC

Unlocks incredible detail, warmth, and nuance from your digital music

Extensive streaming support

Includes Spotify Connect, TIDAL Connect with MQA, Amazon Music, Qobuz, Deezer, Internet Radio, Apple AirPlay 2, and Chromecast Built-in.

Seamless multiroom integration

Compatible with Google Home, Apple AirPlay, and Roon multiroom systems for synchronized playback across your home.

Flexible connectivity

Features USB playback, RCA/phono, coaxial, optical, and Bluetooth 5.0, supporting hi-res files up to 768kHz 32-bit PCM and DSD512.

Direct access controls

Program the sleek front-panel buttons for instant access to favorite stations or playlists.

Customize your sound

Enhance vocals, tighten bass, or refine treble. Enjoy complete control over your listening experience with 7-band adjustable EQ,

Triangle
Borea - BR04
Hi-Fi Bookshelf Speaker

BOREA BR04 BOOKSHELF SPEAKER

The new BR04 was crafted to enhance the BR03, offering superior performance while maintaining a compact, affordable design. These efforts provide, upgraded performance especially in the bass, while retaining the qualities that made the BOREA range successful.

The BR04 integrates the EFS silk-dome tweeter and a cellulose pulp midrange/bass driver, ensuring clear vocals and natural warmth. The elegant design is available in six finishes, offering the flexibility to fit in any décor.

Additional improvements include a redesigned front bass-reflex port and an expanded cabinet, optimizing airflow for deeper, more controlled bass. The addition of double binding posts, combined with an upgraded crossover, enables bi-wiring and bi-amplification for enhanced sound precision.

With a frequency range from 44 to 22,000 Hz and a sensitivity of 90 dB, the BR04 is perfect for rooms from 10 to 40 m2. It offers rich, detailed sound for both Hi- Fi and home theater setups, ensuring a versatile and immersive listening experience.

NEW REFERENCE BOREA BOOKSHELF

Push the limits of the BR03

The BR04 was born of the desire to push the limits of the famous BR03, offering even better performance in a compact bookshelf speaker. With the BR04 TRIANGLE is containing the tradition of offering affordable high performance in the BOREA speaker range. The BR04 benefits from several improvements that enhance low-frequency sound reproduction, while gaining clarity.

COMPACT, HIGH-PERFORMANCE LOUDSPEAKERS

Extended Frequency Response

The BR04 is a two-way bookshelf loudspeaker that can be placed on a dedicated stand or placed on a bookshelf or counter.

• The 25mm silk dome tweeter combined with a waveguide (EFS Technology) ensures precise sound and even sound diffusion.
• The 16cm-diameter bass-midrange with a natural cellulose pulp membrane for a warm, realistic reproduction of vocal timbre. The cone profile has been reworked to reduce distortion at high frequencies, for a clearer sound at high volumes.

The new BOREA BR04 is perfect for rooms ranging from 10 to 40m², delivering rich, detailed sound.

NEW TUBULAR VENT

Optimized airflow

The BR04 features a new bass-reflex port on the front, optimizing airflow for deep, controlled bass. This reduces turbulence and delivers more accurate sound reproduction.

The larger cabinet size extends the frequency response in the bass range from 44 to 22,000 Hz, with a sensitivity of 90db/W.

The front port allows the BR04 speaker to be positioned with more flexibility even against a wall without compromising sound quality

DOUBLE BINDING POST

For Audiophile Set-up

The BR04 employs new double binding posts with a redesigned crossover architecture, separating mid-bass frequency processing from high frequencies. This configuration allows the speakers to be used in bi-wiring and bi-amplification.

This approach guarantees more accurate and faithful sound reproduction. Ideal for audiophiles in search of the finest detail, it offers a sound experience of exceptional purity and precision.

DVAS SYSTEM

Absorption of parasitic vibrations

TRIANGLE's exclusive DVAS (Driver Vibration Absorption System) reduces vibrations by cleverly integrating the drivers into the speaker structure.

This improves the rigidity of the whole to attenuate any parasitic frequencies. This process attenuates vibrations generated by the movement of the midrange driver.

The result: sound reproduction gains in clarity, detail and dynamics.

Meticulous Design

EXCLUSIVE AMERICAN FINISHES

The new bookshelf loudspeaker is inspired by the aesthetics of the Borea range, combining elegance, authenticity and a return to natural materials. It is distinguished by six unique finishes: Black, Chestnut, Light Oak, Oak Green, Light Oak Blue and White, allowing it to blend perfectly with any interior style.

Fabric grilles with magnetic fastenings add a touch of refinement while protecting the loudspeakers, combining meticulous design and functionality.

ADAPTED RUBBERS PADS FOR STANDS

IMPROVED SET-UP

The BR04 loudspeaker features a new dual-function rubber pad system: :

• it effectively dampens vibrations generated by the speaker and reduces unwanted resonances, ensuring greater acoustic clarity

• its ingenious design holds the speaker firmly to your speaker stand, whatever model you choose. This added stability prevents any slippage or imbalance, guaranteeing an optimal experience.

Speaker informations

• Type: Bass Reflex Bookshelf with front bass reflex port

• Crossover: 2 Ways

• Sensitivity: 90 dB

• Bandwidth (+/- 3dB): 44 – 22,000 Hz

• Nominal impedance: 8Ω

• Minimum impedance: 4.6 Ω

* The impedance of a speaker can be simplified as an electrical resistance. The lower is the impedance of the speaker, the more current the amplifier will have to deliver.

- Nominal impedance is measured at a frequency of 1kHz

- Minimum impedance is measured at low frequencies.

TRIANGLE loudspeakers never fall below 3 Ohms, which means they can be used with almost all Hi-Fi and Home Cinema amplifiers.

Music Hall Stealth Turntable

Product Highlights:

• 3-speed direct drive turntable with touch-activated speed controls
• Brushless, low-torque motor automatically stops running at the end of a record
• Heavy, multi-layer chassis and height-adjustable feet attenuate external vibrations
• S-shaped tonearm with VTA adjustment and detachable headshell
• Factory-mounted, precision-aligned Ortofon 2M Blue cartridge
• Vibration-damping rubber platter mat and feet reduce unwanted resonance and noise
• Automatic standby mode after 20 minutes of non-use
• Removable RCA cables and cloth dust cover included

Dimensions and Warranty:

• Dimensions: 17.83" x 14.24" x 5.78"
• Weight: 24 lbs.
• Warranty: 1 year

All About Music Hall Stealth Turntable

The Music Hall Stealth Turntable is a game changer for vinyl enthusiasts. The first direct drive turntable from Music Hall, the Stealth features a brushless, low-torque motor that automatically stops running at the end of a record. But that's not all - this 24-pound turntable is built with an unusually heavy, multi-layer and well-damped chassis, and large, viscous-elastomer damped height-adjustable feet that attenuate external vibrations.

With touch-activated speed controls for ease of use, the Stealth is a 3-speed direct drive turntable that comes complete with an S-shaped tonearm, a detachable headshell, and a factory-mounted, precision aligned Ortofon 2M Blue cartridge. You can adjust the VTA of the aluminum tonearm while the record is playing, and the platter is a hefty 4-pound, elastomer-damped aluminum construction.

The Stealth is not just a beautiful turntable - it's a sound foundation for your vinyl collection. The vibration-damping rubber platter mat and feet work together to reduce unwanted resonance and noise, while the Ortofon 2M Blue cartridge delivers a clear, detailed sound. And when you're done listening, simply use the touch controls to stop the motor, or let the automatic standby mode kick in after 20 minutes of non-use. The Stealth also comes with removable RCA cables and a cloth dust cover for easy storage. Overall, the Music Hall Stealth Turntable is a top-of-the-line choice for vinyl enthusiasts looking for a direct drive design and exceptional performance.

Turntable Type: 3-speed full manual, Auto stop

Cartridge Type: Moving magnetic cartridge

Motor: Brushless motor (Low torque)

Driving Method: Direct drive

Turntable Platter: 305mm (12”) dia. Aluminum die-cast

Speed: 331/3, 45 and 78rpm

Wow and Flutter: Typical: Less than 0.07% WTD at 3kHz RMS (CD-4005), Limit: Less than 0.12% WTD at 3kHz RMS (CD-4005)

Signal-to-noise ratio (for MM): Typical: More than 70dB DIN-B (SS-4242), Limit: More than 65dB DIN-B (SS-4242)

Speed Tolerance: Constant Speed 3000Hz +/-0.3% (CD-4005)

Channel Separation: Typical: More than 20 dB at 1kHz (CD-4005), Limit: More than 15 dB at 1kHz (CD-4005)

Channel Balance: Typical: Within 1.5 dB at 1kHz (CD-4005), Limit: Within 2 dB at 1kHz (CD-4005)

Phono Output Level: Typical: 5.5mV -3dB/+1dB: 3.894mV6.172mV at 1KHz 5cm/sec (CD-4005), Limit: 5.5mV -4dB/+2dB: 3.471mV6.925mV at 1KHz 5cm/sec (CD-4005)

Frequency Response (Phono Output): Typical: 20Hz20kHz +/-0.5dB, Limit: 20Hz20kHz +/-1dB

Brushless motors torque (Direct drive): Typical: More than 1.2kg, Limit: More than 1.0kg

Power Supply: DC12V，2.0A

Standby Power consumption: Less than 0.3 W, Auto stop on more than 20 minutes

Dimensions (WxDxH): 17.83" x 14.24" x 5.78" (455 x 361.67 x 146.7mm)

Weight: 24 lbs.(11 Kgs)

Cartridge: Ortofon 2M (Bule)

Output Voltage: 5.5mV at 1 kHz, (5 cm/sec)

Channel Separation: Measurement point 1KHz over 25dB

Channel Balance: 1.5dB or less at 1kHz

Frequency Response: 20Hz ~ 20kHz +2/-1 dB

Vertical Tracking Force: 1.6～2.0g (1.8g, Recommended)

Tonearm

Type: Static balanced S-shaped tonearm with detachable head shell

Effective Arm Length: 230mm (9”)

Overhang: 15mm (0.59”)

Offset angle: 22⁰

Tracking Error Angle: Less than 3 degree

Applicable cartridge weight: 6~10g

Anti-skating adjustment range: 0~4g

Height of cue (first track): 8~10.5mm

The SANUS Basic Foundation Series BF24B Wood Speaker Stands feature:

• A beautiful, black-ash finish.
• 20 lb top-plate weight capacity.
• Twin contoured pillars aligned in a "V" configuration to offer secure support and style
• A hidden cable management system with a snap-in, curved black cover to hold wires in place and hide them from both front and back view.
• A softly curved black base.
• MDF (Medium Density Fibercore) construction, offering more strength than plywood or particle board and ensuring immunity from resonance.
• Force-fit floor spikes to further minimize resonance and provide stability in carpeting.
• Special, triangular top plate isolation pads for speaker protection and acoustic isolation.
• Price is per pair.
• Top Plate Dimensions: 6.5" x 6.5"
• Base Plate Dimensions: 12.5" W x 11" D
